Toray TM820V-400 8040 is a high-performance seawater reverse osmosis (SWRO) membrane designed for efficient seawater desalination and industrial water treatment applications.
The Toray TM820V-400 8040 is an 8-inch × 40-inch seawater reverse osmosis (SWRO) membrane designed for efficient seawater desalination and high-salinity water treatment. Its spiral-wound thin-film composite membrane construction is designed to provide high salt rejection and reliable permeate production in demanding seawater RO applications. The standard 8040 configuration makes the membrane suitable for large-scale commercial and industrial desalination systems. The TM820V-400 is designed to remove dissolved salts, minerals, and other contaminants from seawater, producing high-quality permeate for drinking water, industrial process water, and other applications. The membrane is suitable for seawater desalination plants, municipal drinking-water production, industrial water treatment, marine applications, and water-reuse systems. Proper pretreatment is essential to control suspended solids, fouling, scaling, and other feed-water conditions that can affect membrane performance and service life. Key Features Designed specifically for Seawater Reverse Osmosis (SWRO) Standard 8040 (8" × 40") membrane configuration Spiral-wound membrane element design Thin-Film Composite (TFC) membrane construction High salt-rejection capability Designed for high-salinity seawater feed Suitable for large-scale desalination systems Efficient removal of dissolved salts and contaminants Suitable for properly pretreated seawater Designed for consistent permeate quality Suitable for industrial and municipal water treatment Applications Seawater desalination plants Municipal drinking-water production Industrial seawater RO systems Coastal desalination projects Marine and offshore water treatment Industrial process-water production High-salinity water treatment Water-reuse and recycling systems Power and industrial water treatment Product Details Brand: Toray Model: TM820V-400 Element Size: 8040 (8" × 40") Membrane Type: Seawater Reverse Osmosis (SWRO) Configuration: Spiral-Wound Application: Seawater Desalination and High-Salinity Water Treatment Note: Actual permeate flow, salt rejection, operating pressure, temperature, and other performance values should be verified against the current Toray technical datasheet for the exact TM820V-400 specification and operating conditions.
Model: TM820V-400 Capacity: 10,500 GPD (39.7 m³/day)
Brand: Toray Series: TM800V Low-Energy Model: TM820V-400 Membrane Type: Seawater Reverse Osmosis (SWRO) Element Size: 8040 (8" × 40") Membrane Construction: Cross-linked fully aromatic polyamide composite Active Membrane Area: 400 ft² (37 m²) Nominal Permeate Flow: 9,000 GPD (34.1 m³/day) Minimum Permeate Flow: 7,500 GPD (28.4 m³/day) Nominal Salt Rejection: 99.80% Minimum Salt Rejection: 99.50% Feed Spacer: 34 mil Test Pressure: 800 psi (5.52 MPa) Maximum Operating Pressure: 1,200 psi (8.3 MPa) Maximum Feed Temperature: 45°C (113°F) Maximum Feed SDI₁₅: 5 Continuous Operating pH: 2–11 Cleaning pH Range: 1–12 Maximum Pressure Drop per Element: 15 psi Element Diameter: 7.9" (201 mm) Element Length: 40" (1,016 mm) Permeate Tube Diameter: 1.125" (29 mm) Toray identifies the TM820V-400 as a low-energy seawater RO membrane for seawater desalination and high-salinity applications. The published flow and rejection figures are based on specified test conditions, so actual system performance can vary.
Designed specifically for Seawater Reverse Osmosis (SWRO) Low-energy membrane design for efficient seawater desalination Standard 8040 (8" × 40") configuration Approximately 400 ft² (37 m²) active membrane area Nominal permeate flow of approximately 9,000 GPD (34.1 m³/day) Nominal salt rejection of approximately 99.80% Cross-linked, fully aromatic polyamide composite membrane Spiral-wound membrane element construction 34-mil feed spacer Designed for high-salinity seawater feed High salt-removal performance Suitable for large-scale desalination systems Suitable for municipal and industrial seawater treatment Designed for reliable permeate production Suitable for properly pretreated seawater Supports energy-efficient RO system operation
Brackish water reverse osmosis (BWRO) plants Industrial RO water treatment systems Municipal water treatment Groundwater purification High-TDS water treatment Industrial process-water production Commercial water purification Industrial water reuse and recycling Boiler feed-water treatment Pretreatment for demineralization systems General industrial water purification Brackish-water desalination applications
